Product advantages

Sound insulation load: 42db-50db according to international test standards;
High strength fire resistance: according to international test standards, the fire resistance limit is up to 120 minutes.
Integrated molding: high precision, no length limit, which can meet the endless design concept of designers.

Precise positioning: the high-precision metal decorative lines can realize the consistent spacing between modules from beginning to end without deviation, so as to ensure the beauty of lines.

Panel fastener integration: without the help of other fasteners, the installation procedure is simplified to shorten the decoration time and save labor cost to the greatest extent.

Convenient installation structure: no longer worry about finding a professional installer.
Wall structure: all steel system
Wall appearance: the wall thickness is 100mm, the height of upper and lower rails is 40mm, and the module spacing is 6mm.
Fire resistance limit: ei120min
Impact strength: 550nm
Sound insulation load: 42db-50db

Panel assembly: 0.8mm environmental protection galvanized steel plate or stainless steel plate is used for rolling forming, the surface is sprayed or frosted, and 15mm gypsum board is lined; Integrated design of panel fasteners.

Note: the width of steel panel is between 300-1150mm, and the height is not limited. Only transportation and loading need to be considered. The panel surface can be sprayed with solid color or painted with wood grain color,
with rich and diverse colors and lines.
