The full double glass system is a full glass partition that integrates full transparency and disassembly. It has flexibility and stability, and is seamlessly connected with the existing partition products. There is no metal frame in the middle of the overall wall, and there is no visible metal skeleton connection between the glasses. Instead, it is German imported transparent tape with a thickness of only 3mm, which has unparalleled transparency and sound insulation effect.

Wall structure: all aluminum system

Wall appearance: the wall thickness is 100mm, the height of upper and lower rails is 76mm, and 3mm thick transparent tape imported from Germany is used between modules.

Glass assembly: safety or fireproof glass with a thickness of 12mm.
Fire resistance limit: 60min
Impact strength: 450nm
Sound insulation load: 45db-60db

Suggestion: in order to achieve better sound insulation effect of double-layer glass, it is best to configure glass with different thickness on the front and back, and the area of single glass shall not be greater than 3 ㎡. At the same time, unnecessary costs during transportation shall be considered.

Aluminum glass office partitions

Specification: the aluminum surface is anodized alkali sand treatment, and the conventional color is silver. Other relevant colors can be customized according to the actual needs of customers

Description: sound insulation: 45-65db (in line with the sound insulation requirements of normal office environment) V louver allows the ingenious combination of privacy and publicity of the office, which can achieve the spatial effect of proximity and relative isolation between leaders and employees. Aluminum color: the aluminum surface is treated with anodized alkali sand, the conventional color is silver, and other relevant colors can be customized according to the actual needs of customers.

Parameter description:

specification: standard maximum module (width) × high × Thick); v (2400W × 3000H × 80D)

aluminum color: the aluminum surface is anodized alkali sand treatment, and the conventional color is silver. Other relevant colors can be customized according to the actual needs of customers
fire resistance rating: above 70min

sound insulation: 45-65db (in line with the sound insulation requirements of normal office environment) V louver allows the ingenious combination of privacy and publicity of the office, which can achieve the spatial effect of proximity and relative isolation between leaders and employees.

Material description of louver interval
internal structure: anodic aluminum alloy profile connection and fixation
external frame: assembled from high-precision oxygen electrode alumina alloy profile.

double sided glass: a layer of 5mm thick tempered glass is used on both sides of the aluminum frame, and the four sides of the glass are embedded in the aluminum alloy parts and fastened.
metal shutter: external knob, 25mm wide shutter, 0.2mm thick
